D&K EXP 42 Plus 42" Thermal Laminator w/ Stand 1 /Each
8568.750000
NewCondition
InStock
D&K EXP 42 Plus 42" Thermal Laminator w/ Stand 1 /Each
Item #: 04DKEXP42P
Brand:
D&K
Log in for pricingor
- EXP 42 Plus is a mounter, laminator, & encapsulator
- Fast set up and easy operation
- Roller lift for easy film loading
- Optional in-line slitter for trimming during lamination
- 1 Year Manufacturer Warranty / 6 Months on Rollers
Description
The D&K EXP 42" Plus Wide Format Laminator is a heavy duty, industrial strength wide format laminating machine. It features variable speed, heated rollers, a release liner rewind, with a stand. It is designed for multi-purpose laminating and is ideal for wide format digital output. The EXP 42" Plus Laminator is a perfect fit for all of your print finishing needs, and much more.
Features:
- EXP 42 Plus is a mounter, laminator, & encapsulator
- Fast set up and easy operation
- Roller lift for easy film loading
- Optional in-line slitter for trimming during lamination
- Variable roller pressure
- Heavy duty stand with castors make unit easy to move around the shop and offers the ideal height for operator comfort.
- Accepts low-melt, thermal and pressure sensitive films
- Accommodates substrates up to 1/2" thick and rolls up to 8" diameter.
- Ready and wait lights indicate when laminator has reached preset temperatures.
- Independent upper and lower electronic temperature controls with LED display.
- Spring loaded adjustable pressure on laminating and pull rollers for smooth and even lamination.
- Optional footswitch allows hands free operation for guiding materials during lamination.
- Auto-grip shafts for easy loading of film.
- Designed for mounting and laminating low temp, thermal and pressure sensitive films.
- Heated Rollers for a variety of films and scratch free graphics.
- Heavy-duty forward / reverse variable speed motor.
- Sturdy feed-back table with adjustable feed guide
- Heavy-duty top grade silicone rubber rollers
- Heavy duty chain and sprocket drive
- Four high capacity forced air cooling fans.
- Made in the USA
Available Options:
- Foot Switch
- Release Liner Take-up for PSA film
- Slitter Kit
Specifications
Item # | 04DKEXP42P |
---|---|
Manufacturer | D&K |
Manufacturer Item # | EXP42+ |
Working Width | 41" |
Maximum Aperture | 1/2" |
Maximum Speed | 0 to 10 feet/min |
Roller Diameter | 3" |
Power | 230V 60Hz 30 A 1Pz |
Size | 57" W x 19 1/4" H x 27 1/2" D (with feed tray, without stand) |
Weight | 205 lbs. |
Shipping Weight / Size | 420 lbs. / 72" x 40" x 38" |
